Item Requirements
○
Article Name: Strain/Voltage Monitoring Equipment
○ Type and Quantity
Item No.
Item
Q'ty
1
16ch Strain/Voltage Compact Recorder
Includes :
- Input cable for strain and voltage
- Bridge Box (16ch, 350ohm)
- AC Adapter
- Control & Analysis software
- Battery Unit
- Remote Control Unit
- Carrying Case
1 set
○ Latest Delivery Date: 90 days from the Effective Date of Contract
○ Requirements
General Feature
Compact recorder shall support standalone recording and online recording
through a LAN or USB connection.
Modular type for easy expansion and up to 128 channels. 16 channel
strain/voltage measuring unit shall be included
Shock resistance: 490 m/s2 (50 G)
All channels synchronous 20 kHz (For 4 channels) Measurement of 1 channel at
max. 100 kHz
Synchronous sampling of all channels shal be supported with minimum
frequency 1kHz
Rechargeable battery power unit mounted on the main body shall be included to
supply electrical power during minimum 1 hour
Main Unit
Data Saving location : PC & SD Card
Interface : USB 2.0, Ethernet
Measurement Setting method : Online (PC software), Offline (SD card)
Sampling : Max 100kHz
Recording Mode : Manual, Trigger, Interval
Power : 10~30V DC, 100~240VAC (by AC Adaptor), Battery unit
Vibration resistance : 49 m/s2 (5 G)
Shock resistance : 490 m/s2 (50 G)
Strain/Voltage Unit
Measuring targets : Strain gage, Strain gage transducer, Voltage
Bridge/Sensor Excitation : 2.5V DC
Measuring range
Strain ; Minimum 1000 X10-6 strain , Maximum 50000 X10-6 strain
Voltage ; Minimum 1V, Maximum 50V
Accuracy : within ±0.1% FS
Battery Unit
Battery : Li-ion battery
Input DC : 10~30V DC
Output : 10V DC
Discharging time : during 2.5A (25w) output ; 60min or more
Control Software
Y-time, X-Y, bar graphs, circular meters, and numeric display are possible
Measuring condition setting, data acquisition, data collection, data reproduction
and file conversion. For analyzing the acquired data
Analysis Software
Allow a data file to be processed for waveform display, FFT analysis, statistic
operations, header information display, tabulation of numeric dataand setting
display conditions.
Extracts and converts the data files into CSV files.
Arithmetic operations, Histogram analysis, Filtering, Differentiation & integration
Remote Control Unit
Operation Button : REC, STOP, BAL, OPTION1, OPTION2
Carrying Case
Inner Size : 55.3 X 42.4 X 27 cm
IP67 / Def Stan 81-41/STANAG 4280
All Standard accessories should be supplied
One year warranty
○ Payment terms
Payment for the contract shall be made as follows:
Ratio
Payment terms
100%
Receipt of Invoice and Final Acceptance
of products by KARI
