SE Form 0803
FEB 2006
Korea Aerospace Research Institute
GEO-KOMPSAT PROGRAM
DIMENSION
R
E
V
.
N
EW
K
S
P
9
0
0
9
1
2
R
E
V
.
“
N
E
W
”
F
IR
S
T
I
S
S
U
E
.
DRAWN
DATE
FULLY THREADED TITANIUM
HEXAGONAL SOCKET HEAD
CAP SCREW
STANDARD PART
CHECKED
DATE
KSP900912
REV.
NEW
CHECKED
DATE
APPROVED
DATE
GEO-KOMPSAT PROGRAM
SHEET 1 OF 5
SE Form 0803
FEB 2006
Korea Aerospace Research Institute
GEO-KOMPSAT PROGRAM
R
E
V
.
N
EW
K
S
P
9
0
0
9
1
2
STANDARD PART
KSP900912
REV. NEW
GEO-KOMPSAT PROGRAM
SHEET 2 OF 5
SE Form 0803
FEB 2006
Korea Aerospace Research Institute
GEO-KOMPSAT PROGRAM
MATERIAL : TITANIUM(6Al-4V) IN ACCORDANCE WITH AMS4928 or AMS4967.
FINISH : PASSIVATE IN ACCORDANCE WITH AMS2487 or AMS2488 AND
SOLID FILM LUBRICANT(MOLYKOTE 106 or EQUIVALENT)
Caution) Apply solid film except the top of the screw head and
Hexagonal socket
<SCREW WITH PASSIVATION AND SOLID FILM LUBRICANT>
R
E
V
.
N
EW
K
S
P
9
0
0
9
1
2
STANDARD PART
SE Form 0803
FEB 2006
KSP900912
REV. NEW
GEO-KOMPSAT PROGRAM
SHEET 3 OF 5
COC REQUIREMENT: CONDUCT VERIFICATION TEST WITH SAMPLES AND SUBMIT ITS
TEST REPORT AS SEEN IN THE FOLLOWING EXAMPLE.
PART NUMBER EXAMPLE :
KSP900912 - M 10 x 32 – 5
GRADE
LENGTH IN METRIC
SCREW SIZE
METRIC
BASIC PART NUMBER(DIN 912 or ISO 4762)
KSP900912-M10x32-5 = M10 SCREW, HEXAGON SOCKET HEAD CAP SCREW,
32MM LONG, SOLID FILM LUBRICANT.
R
E
V
.
N
EW
K
S
P
9
0
0
9
1
2
STANDARD PART
SE Form 0803
FEB 2006
KSP900912
REV. NEW
GEO-KOMPSAT PROGRAM
SHEET 4 OF 5
Korea Aerospace Research Institute
GEO-KOMPSAT PROGRAM
IDENTIFICATION : PARTS MUST BE BAGGED AND TAGGED WITH PART NUMBER,
MANUFACTURER AND DATE PER KPR12-6-0900.
NOTES : UNLESS OTHERWISE SPECIFIED,
1. DIMENSIONS IN METRICS.
2. APPLY SOLID FILM LUBRICANT IN ACCORDANCE WITH KPR9-0902-5-1 AFTER
PASSIVATE IN ACCORDANCE WITH AMS-QQ-P-35.
IF THE PASSIVATED SCREW PROCURED, IT CAN BE APPLIED SOLID FILM
LUBRICANT IN ACCORDANCE WITH KPR9-0902-5-1 AFTER CLEANING IN
ACCORDANCE WITH KPR2-8-3-1, KPR2-22-35 OR KPR2-22-49.
ENGINEERING INFORMATION (REFERENCE) : THESE PARTS ARE BASICALLY
EQUIVALENT PART WITH DIN 912(ISO 4762) EXCEPT FOR SOLID FILM LUBRICANT.
PROCUREMENT INFORMATION : PARTS MAY BE PROCURED INITIALLY UNDER DIN
NUMBER AND REPROCESSED AS REQUIRED TO COMPLY WITH KSP CODING, OR MAY
BE PROCURED AS COMPLETELY FINISHED KSP PARTS.
R
E
V
.
N
EW
K
S
P
9
0
0
9
1
2
STANDARD PART
KSP900912
REV. NEW
GEO-KOMPSAT PROGRAM
SHEET 5 OF 5
SE Form 0803
FEB 2006
< Number of Procurement Unit>
L/I
Dimension
Number of Units
1
M3x12
100
2
M4x8
50
3
M4x10
1650
4
M4x12
200
5
M4x14
300
6
M4x16
100
7
M4x20
200
8
M4x26
100
9
M4x28
50
10
M4x32
50
11
M4x44
100
12
M5x10
100
13
M5x12
50
14
M5x14
170
15
M5x16
70
16
M5x18
115
17
M5x20
70
18
M5x22
450
19
M5x24
330
20
M5x26
70
21
M5x28
20
22
M5x42
130
23
M5x50
50
24
M6x14
160
25
M6x16
70
26
M6x18
120
27
M6x20
270
SE Form 0803
FEB 2006
28
M6x22
250
29
M6x24
20
30
M6x26
40
31
M6x28
110
32
M6x30
550
33
M6x40
50
34
M6x46
350
35
M6x50
290
36
M6x52
50
37
M6x54
25
38
M6x60
25
39
M6x62
104
40
M8x14
35
41
M8x24
75
42
M8x26
70
43
M8x28
90
44
M8x30
60
45
M8x32
80
46
M8x34
20
47
M8x36
20
48
M8x40
20
49
M8x46
120
50
M8x52
120
51
M8x56
20
52
M8x60
50
53
M10x32
25
54
M10x56
25
55
M10x60
50
56
M12x60
50
sum
7939
